磁力輥
關鍵詞：磁力輥，永磁輥，電磁輥，磁力輸送輥，冷剪定尺磁力輸送輥
磁力輥概述：磁力輥又名冷剪定尺寸磁力輸送輥，按磁力類型分為電磁輥與永磁輥兩種，主要用于鋼鐵行業高速線（棒）材廠、型鋼、角鋼、槽鋼的輸送及冷剪前，通過裝置內的磁板吸住線（棒）材層，使線（棒）材按指定速度輸送至冷剪下。能夠嚴格控制線（棒）材的定尺長度，使線（棒）材的定尺長度誤差在±5mm以內，遠高于國標(GB1499.1-2008和GB1499.2-2007)±25mm的要求，大大提高了線（棒）材的正品率。
產品特點
1、? 該產品適用于棒材定尺剪切生產線，用于輸送和控制棒材剪切長度。
2、? 電磁輥結構合理，磁路設計新穎，磁場公布均勻。
3、? 也可以薄板運送。
4、? 磁力開卷器用。
主要技術參數 （≤350℃通電持續率TD-50%）
型????? ?號 ML1-1990T ML1-2690T
外形尺寸 A ? 1262 1372
B 900 900
C 182 233
D 188 260
E 50 70
F 45 60
G 57 88
H 7.5 13
自 重 Kg 210 300
直流電壓 V 48 170
電流（冷態） A 4.9 5.74
功率（冷態） KW 0.48 1.03
資料來源于岳陽長風www.yycfdc.com 網站，由岳陽長風電磁機械有限公司編制，咨詢電話：13789018701。
Magnet roll
Keywords: magnetic roller, magnetic roller, magnetic roller, magnetic roller conveyor, magnetic cold cut length transport rollers
Magnetic roller Overview: also known as magnetic roller cold shear sized magnetic conveyor roller, roller by magnetic force types into two kinds of electromagnetic and permanent magnet roller, mainly for the steel industry, the high-speed line (rod) materials plant, steel, angle, channel delivery and before the cold shear, through the magnetic plate apparatus sucking line (bar) material layer, so that the line (bar) material transported by a specified rate to the cold cut. Can strictly control lines (rods) cut lengths of material, so that the line (rod) material in cut length error within ± 5mm, much higher than the national standard (GB1499.1-2008 and GB1499.2-2007) ± 25mm requirements , greatly improving the rate of quality wire (rod) material.
Features
1, the product is suitable for bars cut to length line for conveying and controlling bar cutting length.
2, reasonable structure magnetic roller, magnetic circuit design, uniform magnetic field is released.
3, the sheet may be transported.
4, magnetic unwinding Used.
The main technical parameters (≤350 ℃ Duty cycle TD-50%)
Type ML1-1990T ML1-2690T
Dimension A 1262 1372
B 900 900
C 182 233
D 188 260
E 50 70
F 45 60
G 57 88
H 7.5 13
Since weight Kg 210 300
DC voltage V 48 170
Current (cold) A 4.9 5.74
Power (cold) KW ??0.48 1.03
Data from the Yueyang winds www.yycfdc.com website by Yueyang electromagnetic Changfeng Machinery Co., preparation, Tel: 13789018701.
